Electrolux Air Conditioning and dehumidifiers

L'Unite compressor Tecumseh CAE4456Y R134A HBP





KM - R134a Fully Hermetically expansion valve operation

Verdichter Compressor
Kälteleistung (W) bei To Cooling capacity (W) at To


Spannung Voltage
15°C 15 ° C
7,2°C 7.2 ° C
5°C 5 ° C
0°C 0 ° C
-5°C -5 ° C
-10°C -10 ° C
-15°C -15 ° C
-20°C -20 ° C
(V) (V)
CAE4456Y CAE4456Y
1904 1904
1396 1396
1233 1233
1009 1009
787 787
604 604
458 458
- -
220-240V 50Hz 220-240V 50Hz

P abs: 698 W P abs: 698 W
Max. Betriebsstrom: 5,0 A Max Current: 5.0 A
Anlaufstrom: 19,0 A Starting current: 19.0 A
Hubraum: 350 cm³ Displacement: 350 cc
Anschl. Conn. SL / DL : 9,5 / 6,35 mm SL / DL: 9,5 / 6,35 mm

 54,5°C Performance at ambient temperature 35 ° C, Superheat 11K, condensing temperature 54.5 ° C

P abs: 1199 W P abs: 1199 W
Max. Betriebsstrom: 8,5 A Max Current: 8.5A
Anlaufstrom: 29,0 A Starting current: 29.0 A
Hubraum: 887 cm³ Displacement: 887 cc
Anschl. Conn. SL / DL : 15,9 /7,9 mm SL / DL: 15.9 / 7.9 mm

Leistungsdaten bei Umgebungstemperatur 35°C, Sauggasüberhitzung 11 K, Verflüssigungstemperatur 54,5°C Performance at ambient temperature 35 ° C, Superheat 11K, condensing temperature 54.5 ° C
