Hitachi Air Conditioning Wall Mounted Summit RAK Sales And Spare Parts 2019










NOW IN R32 REFRIGERANT



A++ Energy Rated Product



The R32 Hitachi air conditioning RAK-PED & RPD wall mounted range are highly economical and environmentally friendly. Using the latest compressor and inverter technology keeps power consumption to a minimal, but at the same time providing powerful cooling and heating. All Hitachi’s air conditioning units offer high seasonal efficiencies, with models in the Performance range achieving high seasonal performance SCOP A++ 4.6 and SEER A++ 7.6. ​​The compact dimensions of the Performance model (280 x 780 x 218) are common across the entire range and allow for easier integration.


Enhanced inverter performance and system performance are achieved by the addition of a ‘Direct Current’ drive compressor, resulting in up to 10% more efficient than standard 'AC' (Alternating Current) Systems. The variable speed compressor (inverter) enables the system to rapidly reach the desired room temperature setting. Once the desired room temperature has been achieved the compressor rotation peed is reduced, saving up to 30% in energy usage (when compared to standard fixed speed systems).




A bigger flap on the indoor unit delivers air quickly to every corner of the room and the powerful, sweeping air flow eliminates dead zones and improves the cooling and heating effect. The trapezoidal fan blades cut the air diagonally to minimise air resistance and the conical blade fan ensures a high airflow. With this diagonal air blow, less friction is caused, which reduces noise and improves efficiency. The fan diameter has been increased from the conventional 90mm to 100mm. Includes deodorising and anti-bacterial Wasabi filters as standard.



Volt Free control of the air conditioning system option, used to turn the unit on/off remotely after receiving a signal such as key-card, door or window switch, specifically useful in hotel rooms to prevent unnecessary use. Accessory SPX WDC3 is required.





Product Key Feature's:

  • SCOP A++ 4.6 and SEER A++ 7.6 R32 Inverter Heat Pump
  • Infra-red controller
  • Slim construction 218mm
  • Pipe runs up to  15 meters
  • Low noise 19dBA on low
  • Cold draft prevention on heat pump start up
  • Fault diagnosis
  • Auto re-start after power interruption
  • PRE-CHARGED WITH REFRIGERANT for up to 20 metres pipe length
  • Light weight noise absorbing outdoor unit
  • Volt Free control
  • 5 Years Warranty





RAK_PED Technical Specifications:







Indoor Unit Model

rak-18ped

rak-25ped

rak-35ped

rak-50ped

Nominal Cooling Capacity (min - max)

kW

2.00 (0.90 - 2.50)

2.50 (0.90 - 3.10)

3.50 (0.90 - 4.00)

5.00 (1.90 - 5.20)

Sensible Cooling Capacity

kW

1.99

2.28

2.87

3.47

UK Cooling Capacity (sensible)

kW

1.9 (1.7)

2.4 (2.0)

3.3 (2.5)

4.2 (3.1)

Heating capacity at -7°C

kW

1.75

2.50

3.00

4.00

Nominal Heating Capacity (min - max)

kW

2.50 (0.90 - 3.20)

3.40 (0.90 - 4.40)

4.20 (0.90 - 5.00)

6.00 (2.2- 7.30)

Nominal cooling power input (min - max)

kW

0.58(0.25-1.01)

0.70 (0.25 - 1.29)

1.09 (0.25 - 1.46)

1.56 (0.50 - 2.10)

Nominal heating power input (min - max)

kW

0.62(0.25-0.97)

0.88 (0.25 - 1.25)

1.10 (0.25 - 1.70)

1.66(0.50 - 2.75)

Seasonal Efficiency SEER(4)

Energy Efficiency Class Annual Energy Consumption



kWh/yr

5.80

5.80

5.85

5.88

A+

A+

A+

A+

121

151

209

298

Seasonal Efficiency SCOP(4) (Average Climate)

Energy Efficiency Class Annual Energy Consumption



kWh/yr

3.80

3.80

3.80

3.80

A

A

A

A

316

909

1.124

1.601

Nominal Load Efficiency EER / COP(5)

Energy Class (Cool/Heat)



3.45/4.03

3.57/3.86

3.21/3.82

3.21/3.61

A/A

A/A

A/A

A/A

Noise level cooling (sound pressure) (SL / L / M / H)(2)

dB(A)

21/24/33/37

22/24/33/40

25/26/36/43

28/30/40/46

Noise level heating (sound pressure) (SL / L / M / H)(2)

dB(A)

19/22/33/38

20/23/34/41

26/27/36/44

25/30/39/47

Noise level (sound power)(1)

dB(A)

51

54

57

60

Air flow cooling mode (SL / L / M / H)

m3/h

312/350/400/440

333/370/430/510

333/400/485/600

333/450/600/700

Air flow heating mode (SL / L / M / H)

m3/h

312/350/420/480

333/400/500/570

333/520/550/660

433/510/650/770

Dehumidification

l/h

1.2

1.4

1.6

2.0

Dimensions (H x W x D)

mm

280x780x218

280x780x218

280x780x218

280x780x218

Weight

kg

7.5

7.5

7.5

8.0

Power supply



From Outdoor Unit

Drain diameter (ext)



φ16mm

φ16mm

φ16mm

φ16mm



Remote Control

Std

Infra Red (RAR-5F1)

Infra Red (RAR-5F1)

Infra Red (RAR-5F1)

Infra Red (RAR-5F1)

Opt. 1

Wired (SPX-RCDB)

Wired (SPX-RCDB)

Wired (SPX-RCDB)

Wired (SPX-RCDB)

Opt. 2

Wired (SPX-WKT2)

Wired (SPX-WKT2)

Wired (SPX-WKT2)

Wired (SPX-WKT2)







Outdoor Unit Model

rac-18wed

rac-25wed

rac-35wed

rac-50wed

Noise level cooling (sound pressure) (night mode)(3)

dB(A)

45

47

48

50

Noise level heating (sound pressure) (night mode)(3)

dB(A)

46

48

49

50

Noise level (sound power)(1)

dB(A)

59

61

62

64

Air flow (Cooling / Heating)

m3/h

1860/1620

1860/1620

1860/1620

2160/2160

Dimensions (H x W x D)

mm

530x660x278

530x660x278

530x660x278

600x792x299

Weight

kg

24.5

24.5

27.5

40.0



Piping diameter (Liquid / Gas)

Inch

1/4 - 3/8

1/4 - 3/8

1/4 - 3/8

1/4" / 1/2"

mm

6.35 - 9.52

6.35 - 9.52

6.35 - 9.52

6.35 - 12.70

Minimum Piping Length

m

3.0

3.0

3.0

3.0

Maximum Piping Length / Height Difference

m

20/10

20/10

20/10

20/10

Current Quantity of Refrigerant

kg

0.72

0.72

0.95

1.25

Chargeless / Additional Refrigerant Charge

m / g/m

20/ -

20/ -

20/ -

20/ -

Power supply



230V/1Ph/50Hz

230V/1Ph/50Hz

230V/1Ph/50Hz

230V/1Ph/50Hz

Recommended fuse size

A

16

16

16

25

Starting current (cooling/heating)

A

<1 Amp

<1 Amp

<1 Amp

<1 Amp

Running current (cooling/heating)

A

1.09-4.39/1.09-4.22

1.09-5.61/1.09-5.43

1.09-6.35/1.09-7.39

2.17-9.13/2.17-11.96

Interconnecting Cables

No.

3 + E

3 + E

3 + E

3 + E

Working Range (cooling/heating)

°C

-10°C~+43°C / -15°C~+21°C

-10°C~+43°C / -15°C~+21°C

-10°C~+43°C / -15°C~+21°C

-10°C~+43°C / -15°C~+21°C

Refrigerant / GWP



R32 / 1975

R32 / 1975

R32 / 1975

R32 / 1975

Compressor type



Rotary

Rotary

Rotary

Rotary

System Price

(Ł)

480

504

595

791




RAK_RPD Technical Specifications:







INDOOR

Unit

RAK-18RPD

RAK-25RPD

RAK-35RPD

Nominal capacity adjustable



no

no

no

Nominal Cooling capacity (min - max)

kW

2.00 (0.90 - 2.50)

2.50 (0.90 - 3.10)

3.50 (0.90- 4.00)

Cooling sensible capacity

kW

1.94

2.05

2.42

Nominal Heating capacity (min - max)

kW

2.50 (0.90 - 3.20)

3.40 (0.90- 4.40)

4.20 (0.90- 5.00)

Noise level cooling (sound pressure) (SL / L / M / H)

dB(A)

21/24/33/37

22/24/33/40

25/26/36/43

Noise level heating (sound pressure) (SL / L / M / H)

dB(A)

19/22/33/38

20/23/34/41

26/27/36/44

Noise level (sound power)

dB(A)

51

54

57

Air flow cooling mode (SL / L / M / H)

m3/h

312 / 350 / 400 / 440

333 / 370 / 430 / 510

353 / 420 / 485 / 680

Air flow heating mode (SL / L / M / H)

m3/h

312 / 350 / 420 / 480

333 / 400 / 500 / 570

363 / 480 / 570/ 780

Fan Motor

W

30

30

30

Dehumidification

l/h

1.2

1.4

1.6

Dimensions (H x W x D)

mm

280 x 780 x 230

280 x 780 x 230

280 x 780 x 230

Weight

kg

8.5

8.5

8.5

Colour



Star White (N9.3)

Star White (N9.3)

Star White (N9.3)

Condensate Drain

mm

φ 16

φ 16

φ 16

Running current (C/H)

A

1.09-4.39/1.09-4.22

1.09-5.61/1.09-6.52

1.09-6.35/1.09-7.39

Power supply



220-230V

220-230V

220-230V

Cable section (interconnection

mm˛

1.50x 3+EARTH/-

1.50x 3+EARTH/-

1.50x 3+EARTH/-

Piping diameter (Liq / Gas)

Inch

1/4" / 3/8"

1/4" / 3/8"

1/4" / 3/8"

Drain diameter (ext)

mm

φ 16

φ 16

φ 16

Remote control (standard/optional)



RAR-6N1/SPX-RCDB

RAR-6N1/SPX-RCDB

RAR-6N1/SPX-RCDB

Filter



ACL Filter



activated carbon

activated carbon

activated carbon

ACL part name



SPX-CFH25

SPX-CFH25

SPX-CFH25

Pre-filter(Standard/Optional )



WASHABLE/

Stainless-SPX-SPF8

WASHABLE/

Stainless-SPX-SPF8

WASHABLE/

Stainless-SPX-SPF8







OUTDOOR



RAC-18WPD

RAC-25WPD

RAC-35WPD

Nominal Cooling capacity (min - max)

kW

2.00 (0.90 - 2.50)

2.50 (0.90 - 3.10)

3.50 (0.90- 4.00)

Nominal Heating capacity (min - max)

kW

2.50 (0.90 - 3.20)

3.40 (0.90- 4.40)

4.20 (0.90- 5.00)

Nominal cooling power input (min - max)

kW

0.419(0.25 - 1.01)

0.549(0.25 - 1.29)

0.941(0.25 - 1.46)

Nominal heating power input (min - max)

kW

0.519(0.25 - 0.97)

0.733(0.25 - 1.50)

1.000(0.25 - 1.70)

EER / COP



4.77/4.82

4.55/4.64

3.72/4.2

SEER / SCOP



8.50/4.90

8.50/4.90

7.80/4.90

Energy class (SEER/SCOP)



A+++/A++

A+++/A++

A++/A++

Noise level cooling (sound pressure)

dB(A)

44

46

48

Noise level heating (sound pressure)

dB(A)

45

47

49

Noise level (sound power)

dB(A)

58

60

61

Air flow (Cooling / Heating)

m3/h

1860 / 1620

1860 / 1620

1920 / 1620

Dimensions (H x W x D)

mm

548× 750× 288

548× 750× 288

548× 750× 288

Weight

kg

32.5

32.5

32.5

Colour (Munsell Code)



Beige (5Y7/2)

Beige (5Y7/2)

Beige (5Y7/2)

Power supply

V/Ph/Hz

230V / 1Ph / 50Hz

230V / 1Ph / 50Hz

230V / 1Ph / 50Hz

Recommended fuse size

A

15

15

15

Starting current(C/H)

A

2.46/2.93

3.08/3.87

4.81/5.11

Running current (C/H)

A

1.09-4.39/1.09-4.22

1.09-5.61/1.09-6.52

1.09-6.35/1.09-7.39

Cable section (power)

mm˛

1.50x 2+EARTH

1.50x 2+EARTH

1.50x 2+EARTH

Cable section (Interconnection)

mm˛

1.50x 3+EARTH

1.50x 3+EARTH

1.50x 3+EARTH

Piping diameter (Liq / Gas)

Inch

1/4" / 3/8"

1/4" / 3/8"

1/4" / 3/8"

Minimum piping length

m

3

3

3

Maximum piping length / height difference

m

20 / 10

20 / 10

20 / 10

Current quantity of refrigerant / Chargeless

kg

0.870

0.870

0.870

Chargeless length / Additional refrigerant

charge

m / g/m

20/-

20/-

20/-



Working range (cooling / heating)



° C



-10~43/-15~21



-10~43/-15~21



-10~43/-15~21

Refrigerant



R32

R32

R32

Condenser Fan



Propeller Fan

Propeller Fan

Propeller Fan



Compressor

Type



ROTARY

ROTARY

ROTARY

Oil Charge

mL

320±20

320±20

320±20

Oil Type



ACS-68R or equivalent

ACS-68R or equivalent

ACS-68R or equivalent

Coil resistance

Ω

2.167 at 20

2.167 at 20

2.167 at 20

Quantity



1

1

1







PDF Data:





RAK Summit PDF
