Fujitsu Air Conditioning ARYF Floor/Ceiling (concealed) air conditioning Fault Codes

FOR OLD FUJITSU AIR CONDITIONING UNITS PRE 2011:

Error code message:

If "CO" appears in the unit number display, there is a remote control error.

Fujitsu's duct type air-conditioning system offers quiet, efficient operation by way of either ceiling-mounted or floor-mounted units. The compact design of the units allows for easy installation and makes them ideal for situations where space is at a premium. Adjustable via wired remote control, the new duct type units also feature automatic air-flow adjustment.

Key Product Features:

• High power
• Low noise
• Compact design
• Easy installation
• Two air intake options



Indoor Unit	Duty KW	Index	Pipe Size	ASY Wall	AUY Cassette	ARY Fan Coil	ARY Ducted
7	2.2	22	3/8" + 1/4"	ASY07	AUY07	ARY07
9	2.8	28	3/8" + 1/4"	ASY09	AUY09	ARY09
12	3.5	36	1/2" + 1/4"	ASY12	AUY12	ARY12
14	3.8	38	1/2" + 1/4"	ASY14	AUY14	ARY14
18	5.4	54	5/8" + 1/4"	ASY18	AUY18	ARY18
20	5.7	57	5/8" + 1/4"		AUY20
22	6.0	60	5/8" + 1/4"			ARY22
24	6.9	69	5/8" + 1/4"	ASY24
25	7.1	71	5/8" + 1/4"		AUY25		ARY25
30	8.8	88	5/8" + 3/8"	ASY30	AUY30		ARY30
36	10.5	105	3/4" + 3/8"		AUY36		ARY36
45	12.7	127	3/4" + 3/8"		AUY45		ARY45
54	14.1	141	3/4" + 3/8"		AUY54
